ZAM360AL Large-Format Automotive Power Battery FPC Cutting Equipment

ZAM360AL大型自動車用パワー電池FPC切断機

の ZAM360AL大型自動車用パワー電池FPC切断機 is designed for precision processing of flexible printed circuits in electric vehicles. With a working area up to 2000 × 500 mm, dual-drive gantry structure, and CO₂/UV laser options, it delivers accurate, burr-free cuts for battery modules, coverlay films, and automotive electronics. Integrated with CircuitCAM7 and DreamCreaTor software, it ensures high efficiency, distortion compensation, and alignment accuracy within ±5 μm. Ideal for large-scale EV and new energy manufacturing.

カテゴリー: レーザー剥離機タグ: ZAM360AL FPC cutting

説明

No.	Technical Parameter	ZAM360AL
1	Laser Output Power	15W–60W, depending on laser source
2	Laser Pulse Width	Nanosecond / Picosecond
3	Laser Wavelength	355 nm / 532 nm
4	Max. Cutting Thickness	Depends on material, typically < 2.5 mm
5	Max. Processing Area	2000 mm × 500 mm (other sizes customizable)
6	Online Operation	Optional roll-to-roll / sheet loading & unloading
7	Machine Platform	Granite platform, linear motor
8	Data Processing Software	CircuitCAM 7 Laser
9	Machine Control Software	DreamCreaTor 3
10	Machine Dimensions (W × H × D)	1500 mm × 1600 mm × 3000 mm
11	Power Supply	380 VAC / 50 Hz, 3.5 kW

の ZAM360AL is a next-generation cutting solution designed for large-format automotive power battery FPCs. It combines high precision, efficiency, and flexibility to meet the growing demands of electric and smart vehicle manufacturing.

🚗 Tailored for Automotive Applications

Flexible Printed Circuits (FPCs) are increasingly used in automotive electronics due to their lightweight, thin, and flexible properties. They are essential in:

Battery management systems (BMS, VCU, MCU)
Lighting modules
Display systems
Sensors and advanced driver assistance systems (ADAS)

The ZAM360AL ensures clean, accurate, and consistent cutting for these critical components.

🔦 Advanced Laser Processing

Equipped with CO₂ and UV laser options, the system supports both FPC outline cutting and coverlay film processing in one platform.

Large working area up to 2000mm × 500mm
Dual-drive gantry structure for stability and precision
Customisable formats to suit different production needs

📦 Flexible Loading & Unloading

The ZAM360AL supports:

Built-in roll-to-roll or sheet-to-sheet feeding
Integration with third-party automation systems
Configurable combinations for maximum production flexibility

⚙️ Intelligent Software Integration

Automatic data conversion for large-format panels
Multi-point CCD alignment with accuracy better than ±5 μm
Distortion compensation to correct material shrinkage and expansion
Full calibration system including camera, laser, and platform alignment

📈 Enhanced Productivity & Reliability

Optimised cutting paths for reduced cycle time
Strong graphic editing tools for easy data processing
Stable granite base and precision drives for consistent performance

🌍 Application Cases

New energy battery panels – FPC outline cutting
Coverlay film cutting – high-precision, burr-free edges

の ZAM360AL大型自動車用パワー電池FPC切断機 is the ideal solution for manufacturers seeking reliable, high-precision processing in the automotive and new energy industries. With its large working area, advanced laser options, and powerful software, it delivers exceptional results for modern FPC production.
