Specifications
| Model | CAM12A / GAM12 |
|---|---|
| Power | AC110~240V 50/60Hz |
| Normal Rated Power | 70W |
| Counting Capacity | -99999 ~ 99999 |
| Dimension | (L)289*(W)488*(H)177mm |
| Weight | 5.5Kg |
| Applied to | SMT strap parts |
| Strap diameter | It could be applied to various sizes |
| WIDTH of strap | 8,12,16,24,32,44,56mm |
| PITCH of the strap | 2,4,6,8,12,16,20,24,28,32,36,40,44,48 52,.56mm |
| Function | Note / Leakage detection |
Product Introduction
Automatic counting design ensures accurate counting.
Touch screen for easy operation.
Built-in English, Traditional Chinese, Simplified Chinese, Vietnamese, and Korean.
Perpetual calendar with parameter memory.
Manual/automatic counting speed selection.
An optional barcode scanner and printer are available.
Counting data can be transferred to a computer or a USB.
Application Examples
Applicable Products
- Compatible with all SMD tape-type components
- Reel Wheel Diameter: Any size is acceptable
- Strip Width (WIDTH): 8, 12, 16, 24, 32, 44, 56 (mm)
- Strip Pitch (PITCH): 2, 4, 8, 12, 16, 20, 24, 32, 44, 48, 52, 56 (mm)
The CAM12A Counter by SEPRAYS offers a fully automatic counting solution designed to streamline inventory management with speed and accuracy. Equipped with a user-friendly touchscreen interface, the CAM12A Counter supports multiple languages, including English, Traditional and Simplified Chinese, Vietnamese, and Korean, making it adaptable for diverse global operations.
This advanced counter features precise tape and reel inventory tracking, with built-in calendar functionality and battery backup to memorize important data. Operators can choose between manual and automatic inventory speeds, ensuring flexibility to match workflow demands. Optional barcode scanning and printing add further efficiency, while seamless data export to computers or USB drives simplifies record keeping.
Integrated leak detection in the GAM12D model further enhances quality control. Trust SEPRAYS’ CAM12A Counter for accurate, efficient parts counting and inventory management.
Contact us now and discover why over 3,000 leading companies trust SEPRAYS for their PCB depaneling needs.
