ZM300N线下高速磨PCB分板机

规格

Item	Specification
项目	ZM300N
Effective Cutting Size (mm)	370 × 420, 838 × 420 (two-in-one single table)
Cutting Functions	Straight, L-shape, U-shape, circular, arc, dot
Worktable	Dual worktables
Dust Collection Method (External Collector)	Upper or lower dust collection
Spindle Tool Change	Automatic tool change
Tool Detection	Broken tool and automatic detection
Safety Protection	安全光幕
Machine Repeatability	±0.01 mm
Cutting Accuracy	±0.05 mm
Max. Moving Speed	X/Y: 1000 mm/sec, Z: 500 mm/sec
Max. Travel (mm)	X: 860, Y: 720, Z: 100
Spindle Speed	Max. 100,000 rpm
Cutting Speed	1–100 mm/s adjustable
Operating System	Windows10
Programming / Teaching Method	CCD color vision intuitive teaching input
Control Method	精密多轴控制系统
XYZ Axis Drive	AC servo motor
Applicable Tool Diameter	Φ0.8–Φ3.0 mm
Power Supply	AC 220V, single phase, 50/60 Hz, 3.0 kW
Air Supply	0.6 MPa, 120 L/min
Machine Dimensions (W × D × H, mm)	1360 × 1480 × 1500
设备重量	750 kg

Key 产品特点：

1. Precision Cutting

• High-Speed Spindle: Imported precision spindle up to 100,000 rpm for exceptional cutting accuracy.

• CCD Vision System: Automated correction ensures perfect alignment and repeatability.

• Dedicated Jigs: Precisely fix and position the PCB to ensure cutting accuracy and prevent board movement or damage.

2. Low Stress Protection

• Patented floating brush reduces Z-axis stress during cutting.

• ESD-safe spindle and anti-static components prevent circuit damage.

• Protects against solder joint cracks, lifted traces, and component failures.

3. High Productivity

• Dual worktables for simultaneous depaneling and loading/unloading—save waiting time for loading and unloading.

• Offline programming eliminates production line delays.

• Using independently developed control software and motion control, it has been batch-verified by large-scale SMT factories and has strong stability. The hourly output in the same unit time is 30%+ higher than that of competitors.

4. Smart Safety & Easy Operation

• Dual-button start, safety light curtain, explosion-proof motor, and sliding double-door design.

• Windows 10 OS with a user-friendly interface—easy to operate and learn.

• Customizable user accounts with access control.

5. Clean & Dust-Free

• Upper or lower dust collection with airspeed ≥35 m/s and ≥40 m/s.

• Negative pressure detection and an ionizing air gun for maximum dust removal.

• Visually dust-free in SMT production.

6. Application Cases

Why Choose ZM300N?

• 30%+ higher throughput than comparable machines

• 99%+ yield rate proven in mass production

• Global service support with fast response times

• Designed for long-term cost efficiency with low annual maintenance costs

📩 Contact Us for Pricing & Details

Email: sales@seprays.com

WhatsApp: +86-18929266433

Our PCB depaneling solution supports both PCB milling machines and routing processes, providing high-precision CNC cutting for complex PCB shapes.
